CITY University ELEC LAB Complete Electronic Circuits Lab Kit

 Important Price Notice

• Standard Kit Contents:
  Covers all Digital ICs, display, input/output modules, semiconductors, resistors, potentiometers, and capacitors as detailed below.

• Full Engineering Bundle: Adding the “Required Engineering Tools” section will add $40 to the base component price.

• Final price may vary depending on the specific tools you choose to include or exclude.

The CITY University ELEC LAB Complete Electronic Circuits Lab Kit is a professionally curated educational package designed for university-level engineering students enrolled in Electronic Circuits and Digital Logic Design laboratories. The kit provides all essential digital integrated circuits, semiconductors, and passive components required to perform core laboratory experiments in combinational logic, sequential logic, counters, and display interfacing.

It includes a comprehensive set of logic gates, flip-flops, counters, BCD-to-7-segment decoding ICs, and a 7-segment display, along with supporting diodes, resistors, capacitors, and input/output components necessary for practical circuit implementation and verification.

By integrating all required components into a single structured kit, RoboTech Jr. enables students to focus on experimental analysis, circuit design, and concept application rather than component sourcing, ensuring a more efficient and academically focused laboratory experience.

Required Engineering Tools

• Digital Multimeter DT830D+ with Protective Cover & Battery Included
• Large Breadboard – 830 Points
• Plier Long Nose 5 inch
• Jumper Wires 40 Pin Male-to-Male – 20cm
• Screwdriver Set – Cross-Head (Phillips) & Flat
• Soldering Iron 60W with Adjustable Temperature EU Plug
• Solder Wire 0.8mm 20g with Flux
• Desoldering Suction Pump – Aluminum Manual Single
• PCB Breadboard 5×7 cm Single-Sided x2.
• PCB Holder with Magnifier Glass
• Desoldering Wick for PCB & BGA Repair
• LED 5mm with 28mm Long Legs x25 (Red, Blue, Green, Yellow, and White (5 of each).
• Toolbox with Handle – Multi-Compartment Organizer (12-Inch)

Digital Integrated Circuits (ICs)

• IC 7408 – AND Gate
• IC 7432 – OR Gate
• IC 7404 – NOT Gate
• IC 7400 – NAND Gate
• IC 7486 – XOR Gate
• IC 4077 – XNOR Gate
• IC 7473 – Dual JK Flip-Flop
• IC 7474 – Dual D Flip-Flop
• IC 7448 – BCD to 7-Segment Decoder (DIP-16)
• IC 7490 – Decade Counter

Display Components

• 1-Digit 7-Segment LED Display, 5161AS, Common Cathode

Input Devices

• Push Button Switch, 12 × 12 × 7.3 mm * (4Pcs)

Output Modules

• 1-Channel 5V Relay Module with LED Indicator

Diodes

• 1N4005 General Purpose Rectifier Diode
• 1N4004 General Purpose Rectifier Diode
• BZX85C4V3 4.3V Zener Diode

Resistors (1/4W Metal Film)

• 150Ω, 330Ω, 1kΩ, 1.5kΩ, 5.1kΩ, 8.2kΩ, 10kΩ, 15kΩ, 33kΩ, 100kΩ, 1MΩ

Potentiometers

• 1kΩ, 10kΩ

Capacitors

• Ceramic: 100nF
• Electrolytic: 1µF, 10µF, 100µF, 220µF
